Here are the standard dimensions available for our  equal leg channel aluminum extrusions.
All dies subject to verification.

STANDARD

Location Die # A B T T1 R R1 R2 Wt/Ft Perim Special Notes
OLNEY158373.5003.000.250.500.015.015.0154.35018.500
OLNEY128213.6262.500.188.188.015.015.0151.86116.876
OLNEY82644.0001.125.250.250.062.015.0621.72611.894
OLNEY26164.0001.500.125.125.010.010.0101.01313.750
OLNEY16464.0001.500.150.175.087.087.0151.28813.553
OLNEY142304.0001.500.188.188.125.094.1881.47513.194
OLNEY113104.0001.812.188.250.312.031.0621.92414.498
OLNEY42944.0002.000.250.250.250.250.0152.25015.071
OLNEY128574.0002.000.250.250.015.015.0152.28215.285
OLNEY102644.0002.500.375.375.015.015.0153.71317.250
OLNEY32224.0004.000.125.125.010.010.0101.76323.500
OLNEY148024.0004.000.500.500.180.180.1806.56622.382
OLNEY124514.0005.000.188.188.015.015.0153.07327.624
OLNEY134784.0624.500.500.500.015.015.0157.23725.124
OLNEY131294.0631.875.250.250.031.031.0312.19215.016
OLNEY181024.1251.500.125.125.015.015.0151.03114.000
OLNEY26654.1601.250.081.081.010.010.010.63113.158
OLNEY61924.250.500.062.062.010.010.010.38110.375
OLNEY181034.2501.500.125.125.015.015.0151.05014.525
OLNEY127514.2501.750.250.375.015.015.0152.62615.000
OLNEY147994.2811.750.375.500.375.031.0313.64714.410
OLNEY20554.5001.410.188.188.010.010.0101.56614.264
OLNEY181044.5001.500.125.125.015.015.0151.08714.750
OLNEY59974.7501.500.125.125.015.015.0151.12415.250
OLNEY105195.000.763.125.125.062.015.015.94312.749
WYLIE20885.0001.375.375.375.016.188.1883.09614.253
OLNEY181055.0001.500.188.125.015.015.0151.52215.624
OLNEY112145.0001.500.250.250.300.125.0152.28817.148
OLNEY13235.0002.000.188.188.010.010.0101.94517.624
OLNEY42955.0002.000.250.250.250.250.0152.55017.071
OLNEY62565.125.500.062.062.010.010.010.44612.143
OLNEY157655.2503.375.109.109.015.015.0311.63723.740
OLNEY98145.5001.380.125.125.010.010.0101.20116.270
OLNEY181065.5001.500.188.125.015.015.0151.63416.624
OLNEY104895.5001.500.250.250.300.125.0152.43816.147
OLNEY17405.5002.000.125.125.010.010.0101.38718.750
OLNEY98135.5002.130.125.125.010.010.0101.42719.270
OLNEY39305.5621.750.250.250.010.010.0102.57017.620
OLNEY40505.7501.500.125.125.015.015.0151.27617.250
OLNEY107545.8352.813.188.210.187.015.0152.65722.385
OLNEY181076.0001.500.188.125.015.015.0151.75217.624
OLNEY111806.0001.500.250.250.300.125.0152.58817.148
WYLIE109956.1751.507.062.062.016.031.016.67318.234
OLNEY118486.1883.250.210.280.300.031.0313.64624.619
OLNEY32426.5001.500.125.125.010.010.0101.38718.750
OLNEY181086.5001.500.188.125.015.015.0151.85618.625
WYLIE6417.0001.000.080.080.062.016.016.85117.812
OLNEY100167.0002.000.250.250.300.125.0153.18821.152
OLNEY109687.6251.375.125.125.015.015.0151.51920.500
OLNEY50788.0001.500.187.187.010.010.0102.38421.626
OLNEY136418.0002.000.188.188.250.180.0152.63823.255
OLNEY94718.312.500.125.062.010.010.0101.30318.374
OLNEY58388.5621.750.250.250.010.010.0103.46824.125
OLNEY51048.6251.250.250.250.010.010.0103.18821.750
OLNEY51028.6251.750.250.250.010.010.0103.48723.750
OLNEY26149.0001.500.188.188.015.015.0152.62223.624
OLNEY135869.0002.485.285.230.330.140.0155.28726.428
OLNEY1581910.1253.250.375.625.375.125.3758.85231.642
OLNEY1237610.5002.000.250.250.062.015.0154.20228.447

STRUCTURAL CHANNEL - ALUMINUM ASSOCIATION

Location Die # A B T T1 R R1 R2 Wt/Ft Perim
OLNEY46922.0001.000.130.130.100.015.015.5897.654
OLNEY183433.0001.500.130.200.250.015.0151.15811.525
OLNEY46915.0002.250.150.260.300.015.0152.25718.443
OLNEY46906.0002.500.170.290.300.015.0152.89221.404
OLNEY46937.0002.750.170.290.300.015.0153.27024.403

Custom orders available upon request.

For pricing:
Email our sales department, use our Request for Quote online form or call 1-940-564-5681.
